| P/N | Pd(W) | Id(A) | Vdss(V) | Polarity | Package |
|---|---|---|---|---|---|
| 2N7002 | 0.225 | 0.115 | 60 | N | SOT-23 |
| 2N7002K | 0.35 | 0.34 | 60 | N | SOT-23 |
| JMW2301 | 0.35 | -2.3 | -20 | P | SOT-23 |
| JMW2302 | 0.35 | 2.1 | 20 | N | SOT-23 |
| JMW3401 | 0.35 | -4.2 | -20 | P | SOT-23 |
| JMW3402 | 0.35 | 4 | 20 | N | SOT-23 |
| JMW3904 | 0.2 | 0.2 | 60 | NPN | SOT-23 |
| JMW3906 | 0.2 | 0.2 | 40 | PNP | SOT-23 |
| JMW5551 | 0.3 | 0.6 | 180 | NPN | SOT-23 |
| JMW5401 | 0.3 | 0.6 | 160 | PNP | SOT-23 |
| JMW2222 | 0.25 | 0.6 | 60 | NPN | SOT-23 |
| JMW2222A | 0.25 | 0.6 | 75 | NPN | SOT-23 |
| JMW2907A | 0.25 | 0.6 | 60 | PNP | SOT-23 |
| JMWA42 | 0.3 | 0.3 | 300 | NPN | SOT-23 |
| JMWA92 | 0.3 | 0.3 | 300 | PNP | SOT-23 |
| JMW8205 | 0.3 | 0.6 | 600 | PNP | SOT-23 |
| P/N | Pd(W) | Id(A) | Vdss(V) | Polarity | Package) |
|---|---|---|---|---|---|
| 2N60 | 60 | 2 | 600 | N | TO-220 |
| 2N65 | 60 | 2 | 650 | N | TO-220 |
| 4N60 | 104 | 4 | 600 | N | TO-220 |
| 4N65 | 104 | 4 | 650 | N | TO-220 |
| 2N60 | 60 | 2 | 600 | N | TO-251 |
| 2N65 | 60 | 2 | 650 | N | TO-251 |
| 4N60 | 104 | 4 | 600 | N | TO-251 |
| 4N65 | 104 | 4 | 650 | N | TO-251 |
| 2N60 | 60 | 2 | 600 | N | TO-252 |
| 2N65 | 60 | 2 | 650 | N | TO-252 |
| 4N60 | 104 | 4 | 600 | N | TO-252 |
| 4N65 | 104 | 4 | 650 | N | TO-252 |
| 7N60 | 166 | 7 | 600 | N | TO-220F |
| 7N65 | 166 | 7 | 650 | N | TO-220F |
| 10N60 | 200 | 10 | 600 | N | TO-220F |
| 10N65 | 200 | 10 | 650 | N | TO-220F |
| Polarity | PD(W) | IC(A) | Vcbo(V) | Vceo(v) | HFE MIN) | HFE@ VCE(V) | HFE@ IC/IE(A) | R1 | R2 | SOT-523 |
|---|---|---|---|---|---|---|---|---|---|---|
| PNP | 0.15 | -0.1 | -50 | -50 | 100 | -5 | -0.001 | 4.7 | & DT | 1A143TE |
| PNP | 0.15 | -0.1 | -50 | -50 | 30 | -5 | -0.01 | 4.7 | 4.7 | DTA143EE |
| PNP | 0.15 | -0.005 | -50 | -50 | 68 | -5 | -0.005 | 22 | 47 | DTA124XE |
| PNP | 0.15 | -0.1 | -50 | -50 | 56 | -5 | -0.005 | 22 | 22 | DTA124EE |
| PNP | 0.15 | -0.1 | -50 | -50 | 80 | -5 | -0.01 | 2.2 | 47 | DTA123JE |
| PNP | 0.15 | -0.1 | -50 | -50 | 8 | -10 | -0.005 | 2.2 | 2.2 | DTA123EE |
| PNP | 0.15 | -0.1 | -50 | -50 | 100 | -5 | -0.001 | 10 | & DT | A114TE |
| PNP | 0.15 | -0.1 | -50 | -50 | 80 | -5 | -0.01 | 4.7 | 47 | DTA143ZE |
| PNP | 0.15 | -0.1 | -50 | -50 | 68 | -5 | -0.005 | 47 | 47 | DTA144EE |
| PNP | 0.15 | -0.1 | -50 | -50 | 68 | -5 | -0.005 | 4.7 | 47 | DTA114YE |
| PNP | 0.15 | -0.1 | -50 | -50 | 30 | -5 | -0.005 | 10 | 10 | DTA114EE |
| NPN | 0.15 | 0.1 | 50 | 50 | 80 | 10 | 0.005 | 2.2 | 47 | DTC123JE |
| NPN | 0.15 | 0.1 | 50 | 50 | 80 | 10 | 0.005 | 22 | 47 | DTC124XE |
| NPN | 0.15 | 0.1 | 50 | 50 | 80 | 10 | 0.005 | 4.7 | 47 | DTC143ZE |
| NPN | 0.15 | 0.1 | 50 | 50 | 15 | 10 | 0.005 | 4.7 | 4.7 | DTC143EE |
| NPN | 0.15 | 0.1 | 50 | 50 | 8 | 10 | 0.005 | 2.2 | 2.2 | DTC123EE |
| NPN | 0.15 | 0.1 | 50 | 50 | 160 | 10 | 0.005 | 10 | & DT | C143TE |
| NPN | 0.15 | 0.1 | 50 | 50 | 160 | 10 | 0.005 | 10 | & DT | C114TE |
| NPN | 0.15 | 0.1 | 50 | 50 | 80 | 10 | 0.005 | 10 | 47 | DTC144YE |
| NPN | 0.15 | 0.1 | 50 | 50 | 80 | 10 | 0.005 | 22 | 22 | DTC144EE |
| NPN | 0.15 | 0.1 | 50 | 50 | 60 | 10 | 0.005 | 22 | 22 | DTC124EE |
| NPN | 0.15 | 0.1 | 50 | 50 | 35 | 10 | 0.005 | 10 | 10 | DTC114EE |
